ILTIS

Future-oriented control technology for process automation

Control technology for process automation

The ILTIS process control system is a true all-rounder, as it can be flexibly adapted to the size of the plant or the respective industry: Both simple visualisation and complex multi-user systems can be implemented. The required functions can be expanded as required with a wide range of options.

At a glance

  • Supports a large number of PLCs and HMIs
  • Any zoom without loss of quality (WPF)
  • Pipes can be displayed in colour, depending on the medium or temperature
  • Modularly adaptable to the needs of all industries
  • High scalability thanks to modular design
  • Various engineering tools for reduced project planning effort
  • Dashboard for an ideal overview
Download
Brochure ILTIS
1.39 MB, .pdf

Scalable and industry-specific system sizes

For numerous industries and sectors

  • Water and waste water
  • Healthcare and pharmaceutical industry
  • Chemicals industry
  • Hydroelectric power plant
  • Energy management
  • PET recycling
  • Regenerative energies
  • Bulk materials handling
  • Coating technology
  • ...

Scalable system size and function

Scalable system size and function

ILTIS Standard

ILTIS SQL

allows you to read and write directly from your MS SQL database (provided you have the appropriate access rights). This means that data can be exchanged directly between your MES/ERP system and ILTIS.

Logging

guarantees continuous logging of events and faults. The implemented functions make it easier to analyse the processes that have taken place.

Long-term data recording

records the progression of process data and variables over time.

DmsVoyager

is an auxiliary tool for creating key-signal based overviews, setting values and logging/documentation using printable reports.

ILTIS Standard

Excerpt from long-term data logging

Optional expansions

Maintenance managers

provides the appropriate tools to optimally prepare maintenance work for different trades and to procure and carry out material.

ILTIS Web

itallows you to monitor and control the system and analyse process data, whether from the office, from home or on the move via tablet.

ILTIS Recipe

itis a flexible and easy to operate module with which you can implement your recipe controls. ILTIS recipe also puts in consideration significant components of general guidelines of GLP, GMP and FDA.

Maintenance Manager

Excerpt from the Maintenance Manager

Batch-orientated data acquisition

is a user-friendly solution that records, combines and secures the data acquisition for each partial system, batch independently for each process in a batch-orientated manner.
And that is essential, because: Legal requirements as well as our own cost and quality targets demand complete documentation and traceability - and therefore traceability - of the entire production process: from the incoming raw material to the finished product.

Data back-up

of all process data generated during operation automatically and online - in accordance with the selected strategy. The archived files can be easily restored using the integrated DS-Restore function.

Data acquisition

Excerpt from batch-oriented data acquisition


VideoMode

allows you to analyse all process values in detail afterwards. Based on stored data, you can call up all images, trends and logs retrospectively (similar to rewinding a video). VideoMode not only helps you with commissioning and analyses, but also ensures and increases production quality.

Alerting

can be implemented in various functions and options (e.g. AIP).

ILTIS-Report

consists of the actual report and a report editor, which can be used to define and compile the individual reports using drag-and-drop functions.

VideoMode

Excerpt from VideoMode

ILTIS Pipes

is an engineering tool for project planners that greatly simplifies the drawing and expansion of process diagrams. But it is also a helpful information tool for operating personnel, which displays the flow direction as well as the content and status of each pipe in colour.

Skript module

is a feature that can be used to realise comprehensive and customer-specific solutions, such as data exchange with a higher-level system (MES/ERP).

Falke

is a project planning tool for programming the control system and creating process sequences.

ILTIS Pipes

Excerpt from ILTIS pipes

Interfaces, coupling and protocols

Interfaces, coupling and protocols

Common interfaces and couplings

are available for different PLC systems.

OPC UA (Server & Client)

has become an integral part of modern automation. The client/server principle is not only used to link SCADA systems to control systems; OPC has also developed into a universal tool for data exchange thanks to a constant stream of new standards.
ILTIS-PLS has the option of setting up a server or client via OPC (UA & DA).

Benefits to you

Intuitive operation

ILTIS has an intuitive design and makes day-to-day work easy for the operating staff: All processes can be viewed on a central dashboard and the view can be customised. With ILTIS Pipes, the pipes are colour-coded depending on the medium or temperature, which makes it even easier to keep track.

Standardised, modular structure

ILTIS has a modular structure so that all functions can be easily expanded. The optional engineering tools and standardised project planning ensure that engineering effort and potential errors are reduced to a minimum.

Compliance with FDA and GMP guidelines

In the food and beverage industry as well as in the manufacture of pharmaceuticals, production is subject to FDA guidelines and special requirements must be met:  For example, recipes must be stored in a tamper-proof manner and be available in a generally readable form (for example as a PDF). These requirements can be reliably fulfilled with ILTIS.

Dynamic when adjusting recipes

With the ILTIS recipe module, customised mathematical functions can be stored directly in the recipe. If process parameters change, the system automatically and flexibly adapts to these new conditions - guaranteeing that you always end up with the desired product result.

Our partner network

Various automation companies in the beverage industry are able to offer you independent ILTIS engineering. All our Solution Partners are qualified for ILTIS and can therefore independently implement projects according to the Steinecker standard. Our current partner network, consisting of the Solution Partners recognized by Steinecker, can be found in the map below.
